XDN500 Slurry Balance Pipe Jacking

No.1600989488286
规格
修改选择
Model Number: XDN500
XDN500
Power: 37kW
37kW
选择规格和数量
Model Number: XDN500
XDN500
Power: 37kW
起订量为 0。请再添加 0 件以继续。
37kW
-
小计
-
下载
查看所有下载
  • XDN500 Slurry Balance Pipe Jacking
  • XDN500 Slurry Balance Pipe Jacking
  • XDN500 Slurry Balance Pipe Jacking
  • XDN500 Slurry Balance Pipe Jacking
  • XDN500 Slurry Balance Pipe Jacking

Description

Key attributes

Core Components
Engine, Pump
Machinery Test Report
Provided
Warranty
1 Year
Video outgoing-inspection
Provided
Place of Origin
Jiangsu, China
Weight
3500 kg
Motor power
37kW
Torque
22kN.m
Revolution
14r/min
Force per cylinder
150kN

Packaging and delivery

Selling Units
Single item
Single package size
21X21X21 cm
Single gross weight
21.000 kg

Product descriptions from the supplier

Hot Links





Product Description



XDN500 Slurry Balance Pipe JackingXDN500 Slurry Balance Pipe Jacking









DescriptionUnitParameter value
Pipe diameterIDmmΦ500
ODΦ670
Outer diameter× lengthmmΦ690×3200
Rotation systemMotor powerkW37
TorquekN.m22
Revolutionr/min14
Roll correction systemForce per cylinderkN150
Cylinder numberEA3
Steering angle°3
slurry line diametermmΦ75
Weightkg3500
Jacking system Motor powerkW15
Jacking cylindersThrustkN1000
NumberEA2
Strokemm760×2
Launch shaft dimensionsmmΦ2800
Reception shaft dimensionsmmΦ1900
Charge pump Motor powerkW5.5
Discharge pump Motor powerkW11
Injection pump Motor powerkW4
Packaging & Shipping

XDN500 Slurry Balance Pipe Jacking

We supervise the process from the factory to the port designated by the customer to ensure that the customer's products arrive at the destination accurately and safely.

Company Information

XDN500 Slurry Balance Pipe JackingXDN500 Slurry Balance Pipe Jacking

Our factories have passed the certification of relevant organizations.

For example, ISO, CNAS, IAF and so on.

Products have also passed CE, GHOST certification and so on.

XDN500 Slurry Balance Pipe Jacking

Every year, we regularly attend the Canton Fair, the Philippines, Indonesia, Russia and other construction machinery and building machinery exhibitions.

XDN500 Slurry Balance Pipe Jacking

We have received more than 1000 clients and training engineers from more than 100 countries around the world.

Our Services



XDN500 Slurry Balance Pipe Jacking

 we are famous building machinery manufacturer, professional construction machinery exporter and one stop solution supplier in China, our team have  more than 15 years experience in this field already.

(1)Warranty:Every product issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.

(2)Spare parts:CANMAX is dedicated to provide our clients with genuine spare parts with the highest quality,exact fitness and appropriate function.with our global distributor network,you are guaranteed with fast deliveries and services, wherever you are,please submit your spare parts request to us,and list products name ,description of required parts.we guarantee that your request will be handled quickly and appropriately.

(3)Installation & Maintenance:CANMAX is able to provide with the overall installation of complicated machinery,allowing you to start the normal operation of construction machinery solutions.After installation,we will make inspection of the whole machine,operate equipment,and provide you with testing data reports of installation and operation.

(4)Training:CANMAX offer perfect facilities and comfortable environment and can provide training services to different users. The training sessions include product training, operation training, maintenance know-how, technical know-how training, standards, laws and regulations training and other training, all of which are tailored to fulfill your individual needs. Training programs can be conducted in our factory field, or at the client's site.

(5)Technical Advice: CANMAX can also help customers to coordinate with trained service personnel and provide you with detailed and extensive knowledge. Through our technical advice, your machine life can be significantly extended and sustained high capacity.



XDN500 Slurry Balance Pipe JackingWe have already exported our products to more than 100 countries and regions, including: Africa, the Middle East, South America, Central Asia, Russia, Mexico, Australia, New Zealand, Holland, British, Mongolia and so on.
